Compact Screening Solution for Temporary Bypass Applications and Septage Receiving Stations
The Wilo FSM Mobile Compact Screen provides efficient wastewater screening during maintenance work, plant upgrades and emergency situations. The fully automated unit combines high screening performance with integrated screenings washing and compaction. It can also be used as a rental machine or configured as a septage receiving station, making it an ideal solution for regions with limited sewer infrastructure.

Type
Mobile compact screen with integrated screenings washing and compaction system

Applications

• Temporary bypass screening during plant upgrades and inspections

• Municipal and industrial wastewater treatment

• Septage receiving stations

• Pumped wastewater inflows

• Space-constrained installations

• Emergency and temporary treatment applications

Your Benefits

• High screening efficiency with filter screen or perforated plate screen technology

• Integrated screenings washing and compaction for reduced disposal costs

• Compact design with integrated emergency bypass

• Fully automated operation and easy integration into existing control systems

• Flexible deployment without interrupting plant operations

• Available as a rental solution for temporary applications

• Suitable as a septage receiving station in less sewered regions

Technical Data

• Capacity: 30 to 1,000 l/s (up to 3,600 m³/h)

• Perforation: 2 to 12 mm

• Solids content after compaction: >35%

• Organic content after washing: <50 mg COD/g DS

• Volume reduction: 60 to 85%

• Connections: up to DN 600

• Screen width: 1,000 mm

• Installation angle: 60°

• Weight: up to 4,250 kg (empty) / 8,650 kg (full)

• Material: Stainless steel AISI 304 (V2A) or AISI 316 (V4A)
